Product Detail

Overview

General Specification

General Specification
Material:	PBT/Nylon/UL94/Phosphor Bronze/Brass
Insulation O.D	2.54mm
Withstanding Voltage:	1000V AC / minute
Temperature Range:	-40°C~+105°C
Contact Resistance:	20M Ω /max
Insulation Resistance:	1000MΩ / min
Product Plating	Tin over Nickel

Package Specification

Package-spec_KR2546.pdf

Specification

PS-KR2546-01.pdf

KR2546 Series Connectors

The KR2546 series connectors offer unparalleled reliability, versatility, and superior performance. With a range of unique features, applications, and benefits, these connectors are the preferred choice for various electronic applications.

Featuring a current rating of 3A and a voltage rating of 250V, these connectors ensure robust electrical connections. They operate reliably within a temperature range of -40°C to +105°C, exhibit low contact resistance (maximum 20mΩ), high insulation resistance (minimum 1000MΩ), and can withstand voltages of up to 1000V AC/minute, further solidifying their reputation for reliability and performance.

Advantages

Standardized Pitch

The standardized pin pitch of 2.54mm allows the connector to easily mate with a wide range of boards, greatly simplifying installation and wiring processes while increasing productivity.

High Reliability

Manufactured with high-quality materials to ensure excellent electrical and mechanical properties, enabling the connector to maintain stable connections in various environments, reducing failure rates and enhancing equipment reliability.

Multiple PIN Options

This series offers a variety of pin count options, ranging from 2-pin to 16-pin, to meet the needs of different application scenarios. Whether for small devices or large systems, a suitable model can be found.

Wide Range of Applicability

The KR2546 Series 2.54 Dual Row Pin Connector is suitable for a wide range of applications, including automotive, home appliances, industrial, lighting, and medical fields.

RoHS Compliant

Strictly adhering to the RoHS standard, the product does not contain any harmful chemical substances exceeding the RoHS restricted concentration. This ensures the connector can be safely and stably processed at the high temperatures required for lead-free soldering during manufacturing, complying with environmental requirements while ensuring product reliability and durability.

In summary, the KR2546 Series 2.54 Dual Row Pin Connector holds an important position in the field of electronic connectivity due to its standardized pin spacing, high-quality materials, wide range of pin count options, broad applicability, and compliance with various standards.
